Step 1: Pre-installation preparations
1. Check the list of received equipment (including accessories).
2. Confirm the CT (Current Transformer) specifications; select the specification based on the current rating of your home's main circuit breaker. For example, if the main breaker is 100A, choose a 100A/5A CT. A CT accuracy class of 0.5 or higher is recommended. Ensure the CT aperture is large enough to accommodate your main power cable.
3. Safety preparations: Disconnect the main circuit breaker on the grid side and use a multimeter to verify that the power is off.
[Grid] --- [Electricity Meter] --- [CT Installation Point] --- [Home Main Breaker] --- [Home Appliances]
|
[Anti-backflow Inverter] --- [Solar Panels]
The CT must be installed downstream of the grid connection point (at the main incoming circuit breaker) and clamped onto the main live wire (L-wire) entering the premises. Simply put, it should be placed on the line section between the utility meter and the main switch that feeds your home.
Key considerations:
1. Installation location: The CT must be clamped onto the live wire (L-wire); it must never be clamped onto the neutral wire (N-wire).
2. Installation orientation: The CT features an arrow mark (e.g., P1→P2); this arrow must point in the direction of power flow from the grid to your home (the P1 side facing the grid, and the P2 side facing the load/inverter). If installed in reverse, the system will mistake power consumption for power export, preventing the inverter from generating electricity.
3. Safety precautions: Before installing the CT, ensure that the CT's secondary side (the end connecting to the meter) is properly connected. The secondary side must never be left open-circuited, as this can generate lethal high voltage.
Step 1: Mount the Panels
Securely mount your solar panels on the roof, ensuring they're angled for maximum sun exposure.
Step 2: Connect Microinverters
Now, the easy part. Connect each panel directly to its own micro-inverter. This plug-and-play design eliminates bulky central inverters and complex wiring, making the installation quick and simple.
Step 3: Anti reverse current module installation
Safety first! Turn off your main circuit breaker. Now, let's install the anti-reverse flow module in your electrical panel.
Connect the main power wires to its input ports to activate it.Then, clip the CT sensor around the main live wire. This module is the key to preventing any excess solar energy from flowing back into the grid
Step 4: Grid Connection
Finally, connect the AC output from your micro-inverters to the electrical panel. That's the physical installation complete
And you're done! In just about two hours, you have a safer system that eliminates high-voltage DC risks. The micro-inverters optimize each panel's performance and, with the anti-reverse flow module, ensure zero electricity feeds back to the grid. It's efficient, expandable, and built for over 25 years of smart solar power.
